A BIKE FOR THE WAY RIDERS RIDE

Caledonia doesn’t fit in a box nicely, and we like it that way. It was conceived on our Thursday night rides—routes that often play fast and loose with ‘road ride.’ Modern road riders are looking for bikes to handle long-distance, high pace, no limits, and offer maximum fun—the Caledonia delivers performance, comfort, and speed. Oh, and you can fit a 34mm tire in there. Or 31mm with fenders.

Features

• REMOVABLE FDM: Our bolt-on front derailleur mount is made from high-strength aluminum alloy and attaches to the frame with two countersunk screws. This allows for easy replacement in the event of damage but also enables you to adapt to new standards as they become available or remove the front derailleur mount completely if you choose a 1x system.
• INTEGRATED ACCESSORY MOUNTS: Integrated mounts enable the use of fenders, lights, and computers without compromising the aerodynamics or structure of your bike. The built-in mount systems provide a simple and clean-looking solution.

Specifications

Available Sizes	48cm, 51cm, 54cm, 56cm, 58cm, 61cm
Fork	Cervélo All-Carbon, Tapered Caledonia Fork
Handlebar	Cervélo AB07 Alloy, 31.8mm clamp
Handlebar Sizing	Size 48–51: 38cm • Size 54–56: 40cm • Size 58–61: 42cm
Stem	Cervélo ST36 Alloy
Stem Sizing	Size 48: 80mm • Size 51: 90mm • Size 54–56: 100mm • Size 58–61: 110mm
Seatpost	Cervélo SP19 Carbon, 27.2mm
Seatpost Offset	Size 48–56: 0mm • Size 58–61: 15mm
Saddle	Cervélo Saddle
Bottom Bracket	FSA BBright, thread-together, for 24mm spindle
Headset	FSA IS2 1-1/8 (36°×45°) / 1-1/2 (36°×45°)
Front Thru Axle	Cervélo Aero Thru Axle Front, M12×1.5mm, 127mm
Rear Thru Axle	Cervélo Aero Thru Axle Rear, M12×1.5mm, 170.5mm
Front Wheel	Vision Team i23 Disc, 23mm IW, direct pull, 12×100mm, Centerlock, tubeless compatible
Rear Wheel	Vision Team i23 Disc, 23mm IW, direct pull, 12×142mm, HG freehub, Centerlock, tubeless compatible
Tires	Vittoria Corsa N.EXT TLR G2.0, 700×32c
Shifter / Brake Levers	Shimano 105 Di2, R7170
Crankset	Shimano 105, R7100, 52/36T
Crank Length	Size 48–51: 165mm • Size 54–56: 170mm • Size 58–61: 172.5mm
Chain	Shimano M7100
Cassette	Shimano 105, R7101, 11–34T, 12-speed
Front Derailleur	Shimano 105 Di2, R7150
Rear Derailleur	Shimano 105 Di2, R7150
Brake Rotors	Shimano CL700, Centerlock
Accessories	Cervélo removable fender mounts • Cervélo front computer/accessory mount 810 • Cervélo rear accessory mount
Max Tire Width (Actual)	34mm
